Steel cord conveyor belt:
General Steel Cord Conveyer Belt
It uses the new type steel cord as the tear resistant element. It has high tension strength, small elongation, excellent troughability and high flexibility, and it is applicable for the conveyance of materials with long distance, large freight volume and high speed.
Tear Resistant Steel Cord Conveyor Belt
On one side or two sides vertical that is perpendicular to the lengthways steel cable, evenly lay the reinforcing layer of the steel cable, steel cord, fabric, etc.
It has excellent impact and tearing resistance performance.
Technical Data
|
Technical Data |
Belt Strength |
|||||||||||||
|
ST/S 630 |
ST/S 800 |
ST/S 1000 |
ST/S 1250 |
ST/S 1600 |
ST/S 2000 |
ST/S 2500 |
ST/S 2800 |
ST/S 3150 |
ST/S 3500 |
ST/S 4000 |
ST/S 4500 |
ST/S 5000 |
ST/S 5400 |
|
|
Longitudinal Tensile Strength (N/mm) |
630 |
800 |
1000 |
1250 |
1600 |
2000 |
2500 |
2800 |
3150 |
3500 |
4000 |
4500 |
5000 |
5400 |
|
Max Nominal Dia. of Steel Cord (mm) |
3.0 |
3.5 |
4.0 |
4.5 |
5.0 |
6.0 |
7.2 |
7.5 |
8.1 |
8.6 |
8.9 |
9.7 |
10.9 |
11.3 |
|
Steel Cord Pitch (mm) |
10 ±1.5 |
10 ±1.5 |
12 ±1.5 |
12 ±1.5 |
12 ±1.5 |
12 ±1.5 |
15 ±1.5 |
15 ±1.5 |
15 ±1.5 |
15 ±1.5 |
15 ±1.5 |
16 ±1.5 |
17 ±1.5 |
17 ±1.5 |
|
Thickness of Top Cover (mm) |
5 |
5 |
6 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8 |
8 |
8.5 |
9 |
|
Thickness of Bottom Cover (mm) |
5 |
5 |
6 |
6 |
6 |
6 |
8 |
8 |
8 |
8 |
8 |
8 |
8.5 |
9 |
|
Width (mm) |
Numbers of Steel Cord |
|||||||||||||
|
800 |
75 |
75 |
63 |
63 |
63 |
63 |
50 |
50 |
50 |
50 |
|
|
|
|
|
1000 |
95 |
95 |
79 |
79 |
79 |
79 |
64 |
64 |
64 |
64 |
64 |
59 |
55 |
55 |
|
1200 |
113 |
113 |
94 |
94 |
94 |
94 |
76 |
76 |
76 |
76 |
76 |
71 |
66 |
66 |
|
1400 |
133 |
133 |
111 |
111 |
111 |
111 |
89 |
89 |
89 |
89 |
89 |
84 |
78 |
78 |
|
1600 |
151 |
151 |
126 |
126 |
126 |
126 |
101 |
101 |
101 |
101 |
101 |
96 |
90 |
90 |
|
1800 |
171 |
171 |
143 |
143 |
143 |
143 |
114 |
114 |
114 |
114 |
114 |
109 |
102 |
102 |
|
2000 |
196 |
196 |
159 |
159 |
159 |
159 |
128 |
128 |
128 |
128 |
128 |
121 |
113 |
113 |
|
2200 |
216 |
216 |
176 |
176 |
176 |
176 |
141 |
141 |
141 |
141 |
141 |
134 |
125 |
125 |
|
The Recommended Minimum Pulley Diameter |
||||||||||||||
|
ST Belt Type |
ST/S 630 |
ST/S 800 |
ST/S 1000 |
ST/S 1250 |
ST/S 1600 |
ST/S 2000 |
ST/S 2500 |
ST/S 2800 |
ST/S 3150 |
ST/S 3500 |
ST/S 4000 |
ST/S 4500 |
ST/S 5000 |
ST/S 5400 |
|
Minimum Pulley Diameter (mm) |
500 |
500 |
630 |
800 |
1000 |
1000 |
1250 |
1250 |
1400 |
1600 |
1600 |
1600 |
1800 |
1800 |
